Arrowtech Ultra Cleaning Machine

Arrowtech Ultrasonic anilox roll cleaning machines are fully automated for anilox roll, sleeve & gravure print cylinder maintenance. Individually designed to deep clean anilox rolls, sleeves & gravure print cylinders of all sizes, they reduce set-up times, minimize press downtime, increase the lifetime of the rolls and optimize printing quality.
Arrowtech Ultrasonic anilox roll and sleeve cleaners are a perfect solution for daily washing and maintenance of the rolls. Short and gentle cleaning process leaves the rolls perfectly clean and ready for use in 10 to 20 minutes without damaging the cell walls & engraving structure on ceramic & chrome anilox roll, sleeve & rotogravure print cylinders. Ceramic anilox roll & sleeves cannot be properly cleaned with conventional mechanical methods. The ceramic cell cavities are far smaller than even the finest brush bristles. Although blast systems can clean coarse anilox rolls, only Ultrasonic Cleaners can thoroughly and safely clean the fine count anilox rolls being used today.
Arrowtech ultrasonic cleaning machine is specially designed to remove all types of dried ink i.e. UV, Water & Solvent based inks, Coatings & Adhesives from the ceramic & chrome anilox roll, sleeve & rotogravure print cylinders.

Arrow Print Solutions - Ultrasonic Cleaning Machine

Machine Highlights

Intelligent ultrasonic system: you can freely set the ultrasonic working time and adjust the power. The original degassing purification function can remove Impurities in the water with one key, so that the number of bubbles formed by ultrasonic waves is more, and the “cavitation effect” is maximized, and the anilox roller is cleaned more cleanly.
Intelligent constant temperature system: The temperature can be set freely, and the temperature sensor monitors the water temperature value in real time. When the set value is reached, the system judges to stop heating, when it is less than the set value, the system judges to continue heating to ensure that the water temperature is always in the best state and promotes the high activity of cleaning liquid molecules.
Multiple washes in one machine: Racks are installed on both sides of the machine tank, and a movable adjustment frame is configured. One machine can wash anilox rollers of different lengths, which easily solves the problem of cleaning anilox rollers of different lengths.
Intelligent transmission system: The system automatically adjusts the optimal rotation speed, so that 100% of the anilox roller surface is cleaned in place.
SS 304 stainless steel cabinet: the cabinets are all made of national standard 304 stainless steel, plus the exquisite and beautiful design, not only durable, but also very atmospheric.
Sweepmode technology: the unique frequency sweep mode makes the cleaning solution under the function of frequency sweep, form a small backflow, timely take the dirt peeled off by ultrasound away from the work piece surface, so as to achieve a faster and more thorough cleaning effect.
Time Cleaning: One-key start, the time can be freely set 0 to 60 minutes, after cleaning, the machine will automatically stop working.

Technical Parameters

Model:                                                           AT-370AS                                                                  AT-500A
Inner Tank Dimensions (L*W*H):      500*300*120mm                                                   600*150*120mm
Operating Frequency:                             25 +/- 3 KHz                                                             25+/- 3KHz
Power Consumption:                                    3 KW                                                                           3 KW
Tank Capacity (Approx):                            25 Liter                                                                       15 Liter
Power Input:                                            220 V 50 Hz.                                                              220 V 50 Hz.
Roller Rotation:                               Double Roll or Sleeve                                                        Single Roll

Ultrasonic Cleaning Machine
Ultrasonic Cleaning Machine - Front Face
Ultrasonic Cleaning Machine - Front Face
